Specifications
- power dissipation: R 60mW, G 95mW, B 95mW
- peak forward current (0.1 ms pulse width): 100 mA for each colour
- continuous forward current: 25 mA for each LED
- max. reverse voltage: 5 V
- operating temperature: -40 °C to 80 °C
- dimensions: 28 x 15 x 5 mm
- common: cathode (-)
- attention: current has to be limited by using resistors
-
Specifications
- back-up battery: CR1220 battery (incl.)
- dimensions: 43 x 17 x 9 mm
-
Specifications
- dimensions: 68 x 53 x 12 mm
-
Specifications
- max. current: 20 mA
- connection: 3 pins, only GND (-) and S is used
- weight: 2 g
- dimensions: 35 x 15 x 8 mm
- note: there is no current limiting resistor on the module
-
Specifications
- voltage: 5 VDC
- connection: 3 pins, +(middle pin), ground and DO (data out)
- dimensions: 25 x 15 mm
- weight: 2 g
-
Specifications
- operating voltage: 3.3 VDC
- working current: 13 to 26 mA
- sleep current: < 80 uA
- peak current: < 30 mA
- working frequency: 13.56 MHz
- supported card types: RFID
- interface / protocol: SPI
- controller chip: MFRC522
- data transmission speed: Max. 10 Mbit / s
- dimensions: 66 x 40 x 7 mm
- includes: 2 tags (1 card , 1 fob)
-
Specifications
- voltage: 5 VDC
- connection : 4 pin male header
- pins: GND, RED, GREEN, BLUE
- dimensions: 24 x 16 x 16 mm
- weight: 2 g
-
Specifications
- voltage: 5 VDC
- connection: 3 pins, +(middle pin), ground and DO (data out)
- dimensions: 25 x 15 mm
- weight: 2 g
-
Specifications
- microcontroller: ATmega2560
- operating voltage: 5 VDC
- input voltage (recommended): 7-12 VDC
- input voltage (limits): 6-20 VDC
- digital I/O pins: 54 (of which 15 provide PWM output)
- analogue input pins: 16
- DC current per I/O pin: 40 mA
- DC current for 3.3 V pin: 50 mA
- flash memory: 256 kB of which 8 kB used by bootloader
- SRAM: 8 kB
- EEPROM: 4 kB
- clock speed: 16 MHz
- length: 112 mm
- width: 55 mm
- weight: 62 g
-
Specifications
- microcontroller: ATmega328
- operating voltage: 5 VDC
- input voltage (recommended): 7-12 VDC
- input voltage (limits): 6-20 VDC
- digital I/O pins: 14 (of which 6 provide PWM output)
- analogue input pins: 6
- DC current per I/O pin: 40 mA
- DC current for 3.3 V pin: 50 mA
- flash memory: 32 kB (ATmega328) of which 0.5 kB used by bootloader
- SRAM: 2 kB (ATmega328)
- EEPROM: 1 kB (ATmega328)
- clock speed: 16 MHz
- length: 68.6 mm
- width: 53.4 mm
- weight: 25 g
-
-
| Physical properties |
| Primary colour |
Red |
| Depth unit |
2.7 cm |
| Height unit |
23.5 cm |
| Width unit |
10.5 cm |
| Weight unit |
240 g |
| Material |
Metal |
| Material (Detail) |
Steel |
